1201M1S3ZQE2

C&K - 1000 系列滑动开关C 和 K 系列 1000 微型滑动开关具有环氧树脂密封接线端子，适用于底部冲洗清洁。 它们设计用于各种应用，包括测试和测量设备、电信和计算机外围设备。工作温度范围：- 30 至 +65°C 操作次数；40000 尼龙执行器和己二烯酞酸脂 UL 94V-0 外壳 ### 滑动开关 - 电源

C&K - 1000 系列滑动

C 和 K 系列 1000 微型滑动开关具有环氧树脂密封接线端子，适用于底部冲洗清洁。 它们设计用于各种应用，包括测试和测量设备、电信和计算机外围设备。

工作温度范围：- 30 至 +65°C

操作次数；40000

尼龙执行器和己二烯酞酸脂 UL 94V-0 外壳

### 认可

UL; CSA

欧时:
2 position DPDT panel mount slide switch

立创商城:
1201M1S3ZQE2

e络盟:
C & K COMPONENTS  1201M1S3ZQE2  拨动开关, 1000系列, DPDT, 开-开, 面板, 6 A, 250 V

艾睿:
Turn your circuit on or off using the 1201M1S3ZQE2 slide switch from C&a;K Components. This device has a maximum current rating of 6 A @ 120VAC 28VDC. It has a DPDT configuration. This slide switch has an operating temperature range of -30 °C to 65 °C. The 1201M1S3ZQE2 slide switch has a solder lug termination style. The maximum AC voltage rating is 250 VAC and the maximum DC voltage rating is 28 VDC. This product is 19.56 mm long, 16.64 mm tall and 11.43 mm deep.

Allied Electronics:
Switch; Slide; Sealed; DPDT; ON-NONE-ON; Panel Mnt; Blk .200 Act; 6A; 120VAC; 28VDC; Sldr

安富利:
Switch Slide ON None ON DPDT Top Slide 6A 250VAC 28VDC Solder Lug Panel Mount

Chip1Stop:
Switch Slide ON None ON DPDT Top Slide 6A 250VAC 28VDC Solder Lug Panel Mount

Verical:
Switch Slide ON None ON DPDT Top Slide 6A 250VAC 28VDC Solder Lug Panel Mount Bulk

Newark:
# C & K COMPONENTS  1201M1S3ZQE2  Slide Switch,STRAIGHT,DPDT,ON-ON,SOLDER Terminal

儒卓力:
**SLIDE DPDT ON-On Solderlug pane **

MASTER:
Miniature Slide Switch

Electro Sonic:
Miniature Slide Switch
