1351E-6534

SENSOR; PHOTO-ELEC; 10FOOT DIFFUSE REFLECTIVE; AC-DC; SPDT EM RELAY OUT; 5P AC MICRO

The new Enhanced versions of the Cutler-Hammer® 50 Series™ Photoelectric Sensors from Eaton"s electrical business offer flexibility, durability and high optical performance in a cost-effective self-contained package. Choose from three output types, four sensing modes and three connection styles to tailor the sensor to exactly meet your needs. Sensors are available in thru-beam, reflex, polarized reflex, diffuse reflective, and clear object sensing modes. Brackets are available for easy mounting and to allow precise adjustment of sensor alignment.

.

*

Features:

**

* High Optical Performance Models Including a 500 Foot 152 m Thru-Beam and a 10 Foot 3 m Diffuse Reflective Unit

* Output Options Include a 3 Amp SPDT Relay

* All Units Offer Light/Dark Selection

* Logic Options Include ON-Delay, OFF-Delay and One-Shot Delay

* Fully Potted Construction for Use in Areas Subject to Washdown, High-Shock and/or Vibration

* Choice of Pre-Wired Power Cable, Built-In Microconnector, and Built-In Euro Versions. Standard Pre-Wired Cable Length Is 6 Feet 1.8 m

* Different Brackets Available Including Ball Swivel

* Infrared Light Source

* CSA Approved

* Certified to UL Standard, UL 508
