CT-MBS Series Multifunctional TimersThe CT-MBS series is a set multifunctional electronic timers from the CT-S range. The series can provide up to 10 timing functions and 10 time ranges. All electronic timers from the CT-S range are available with two different terminal versions. You can choose between the proven screw connection technology double-chamber cage connection terminals and the completely tool free Easy Connect Technology push-in terminals.Rated control supply voltage 24 → 48 V dc, 24 → 240 V ac Timing functions: ON delay, OFF delay with auxiliary voltage, Impulse ON, Impulse OFF with auxiliary voltage, Symmetrical ON and OFF delay, Flasher starting with ON, Flasher starting with OFF, Star delta change over with impulse, Pulse former, ON/OFF function 10 time ranges 0.05 s → 300 h Control input with volt free triggering to start timing Remote potentiometer connection Precise adjustment by front face operating elements Screw connection technology or Easy Connect Technology available Enclosure material for highest fire protection classification Tool free mounting and demounting on DIN rail 2 C/O SPDT contacts 22.5 mm 0.89 in width 3 LEDs for status indication ### 认可UL 508, CAN/CSA C22.2 No.14, GOST, CB scheme, CCC, CE & C-Tick### 多功能
CT-MBS 系列多功能计时器
CT-MBS 系列是来自 CT-S 系列的一组多功能电子计时器。该系列可提供多达 10 种计时功能和 10 个时间范围。所有 CT-S 系列电子计时器均可提供两种不同接线端子型号。您可在经过验证的螺钉连接技术（双箱式笼连接接线端子）与完全无需工具的轻松连接技术（推入式接线端子）之间进行选择。
额定控制电源电压 24 → 48 V 直流，24 → 240 V 交流
计时功能：接通延时、断开延时（辅助电压）、脉冲接通、脉冲断开（辅助电压）、对称接通和关闭延时、闪光装置启动（接通）、闪光装置启动（断开）、星三角转换开关（脉冲）、脉冲形成器、接通/断开功能
10 个时间范围 0.05 s → 300 h
使用无电压触发控制输入以开始计时
远程电位计连接
由正面操作元件精确调节
提供螺钉连接技术或轻松连接技术
外壳材料具有最高防火等级
在 DIN 导轨上安装和拆卸时无需工具
2 个 C/O（单刀双掷）触点
22.5 mm 0.89 in 宽度
3 个用于状态指示的 LED
### 认可
UL 508、CAN/CSA C22.2 No.14、GOST、CB scheme、CCC、CE 和 C-Tick
