103328-8

集管和线壳 16P HEADER TIN double row

16 MODII HDR DRST B/A .100CL

Product Highlights

Connector

Housing Gender = Header - Pin

Contact Gender = Pin

Header Type = Breakaway

16 Positions

得捷:
16 MODII HDR DRST B/A .100CL

立创商城:
2.54mm 方针

贸泽:
集管和线壳 16P HEADER TIN double row

艾睿:
Safety is an important concern when designing electronic devices. TE Connectivity&s;s unshrouded 103328-8 header connector helps protect your equipment from accidental shortages. This HDR connector&s;s 16 contacts that are made out of phosphor bronze and plated with tin-lead over nickel. It has a straight body orientation. It has a header type gender. This is a 2-row connector. Its pitch is 2.54 mm. This device has a maximum current rating of 3 A/contact. It uses the solder termination method. This connector has an operating temperature of -65 to 105 °C. This product is 19.91 mm long, 8.13 mm tall and 4.88 mm deep. 103328-8 is housed in black thermoplastic.

安富利:
Conn Unshrouded Header HDR 16 POS 2.54mm Solder ST Thru-Hole

Chip1Stop:
Conn Unshrouded Header HDR 16 POS 2.54mm Solder ST Thru-Hole

Verical:
Conn Unshrouded Header M 16 POS 2.54mm Solder ST Top Entry Thru-Hole Carton

Newark:
# AMP - TE CONNECTIVITY  103328-8  16 MODII HDR DRST B/A .100CL New

MASTER:
ASSEMBLY, HEADER, BREAKAWAY, MOD II, DOUBLE ROW, .100 X .100 C/L, VERTICAL,

Powell:
.100 inch AMPMODU Headers

Online Components:
16 MODII HDR DRST B/A .100CL

Electro Sonic:
16 MODII HDR DRST B/A .100CL
