2SC3357-T1

2SC3357-T1 编带

DESCRIPTION

The 2SC3357 is an NPN silicon epitaxial transistor designed for low noise amplifier at VHF, UHF and CATV band. It has large dynamic range and good current characteristic.

FEATURES

• Low Noise and High Gain

  NF = 1.1 dB TYP., Ga= 8.0 dB TYP. @VCE= 10 V, IC= 7 mA, f = 1.0 GHz

  NF = 1.8 dB TYP., Ga= 9.0 dB TYP. @VCE= 10 V, IC= 40 mA, f = 1.0 GHz

• Large PTin Small Package

  PT: 2 W with 16 cm2 × 0.7 mm Ceramic Substrate.
