219 系列 单刀单掷 3 位置 自动置位 表面贴装 DIP 开关
is manufactured by Electrocomponents and is categorized in the DIP Switches category. 219-3LPSTR is described as SWITCH SLIDE DIP SPST 100MA 20V. Perfect Parts is a supplier of Switches and other Electromechanicals.
得捷:
SWITCH SLIDE DIP SPST 100MA 20V
贸泽:
DIP Switches / SIP Switches 3 switch sections SPST
艾睿:
This 219-3LPSTR dual in-line package switch from CTS can be easily customized and designed to be used on a printed circuit board. This device has a maximum current rating of 0.1 A @ 20VDC. It has a SPST configuration. This DIP switch has a minimum operating temperature of -55 °C and a maximum of 85 °C. The 219-3LPSTR DIP switch has a gull wing termination style. This product&s;s terminal pitch is 2.54 mm. This product is 9.09 mm long, 4.05 mm tall and 9.91 mm deep. The maximum DC voltage rating is 20 VDC.
Chip1Stop:
Switch DIP ON OFF SPST 3 Flush Slide 0.1A 20VDC Gull Wing 2.54mm SMD T/R
Verical:
Switch DIP ON OFF SPST 3 Flush Slide 0.1A 20VDC Gull Wing 2000Cycles 2.54mm SMD T/R
MASTER:
Switch DIP ON OFF SPST 3 Flush Slide 0.1A 20VDC Gull Wing 2000Cycles 2.54mm SMD T/R
额定电压DC 50 V
额定电流 100 mA
针脚数 3
额定电流Max 0.1A @20VDC
工作温度Max 85 ℃
工作温度Min -55 ℃
额定电压 20 VDC
额定电压DC Max 20 V
接触电阻Max 25 mΩ
安装方式 Surface Mount
长度 9.09 mm
宽度 9.91 mm
高度 4.05 mm
触点材质 Beryllium Copper
工作温度 -55℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
219-3LPSTR CTS 西迪斯 | 当前型号 | 当前型号 |
219-3LPSTJ 西迪斯 | 完全替代 | 219-3LPSTR和219-3LPSTJ的区别 |
219-3MSTF 西迪斯 | 完全替代 | 219-3LPSTR和219-3MSTF的区别 |
219-3LPS 西迪斯 | 完全替代 | 219-3LPSTR和219-3LPS的区别 |
