219 系列 单刀单掷 4 位置 自动置位 表面贴装 DIP 开关
DIP SPST 位置 表面贴装型 滑动式(标准) 触动器 100mA 20VDC
得捷:
SWITCH SLIDE DIP SPST 100MA 20V
立创商城:
219-4MSTR
艾睿:
By acting as a series of switches, the 219-4MSTR dual in-line package switch from CTS is the ideal component for use on a printed circuit board. This device has a maximum current rating of 0.1 A @ 20VDC. It has a SPST configuration. This DIP switch has an operating temperature range of -55 °C to 85 °C. The 219-4MSTR DIP switch has a gull wing termination style. The maximum DC voltage rating is 20 VDC. This product is 11.63 mm long, 4.3 mm tall and 9.91 mm deep. This product&s;s terminal pitch is 2.54 mm.
安富利:
Switch DIP ON OFF SPST 4 Raised Slide 0.1A 20VDC Gull Wing 2.54mm SMD T/R
Chip1Stop:
Switch DIP ON OFF SPST 4 Raised Slide 0.1A 20VDC Gull Wing 2.54mm SMD T/R
Verical:
Switch DIP ON OFF SPST 4 Raised Slide 0.1A 20VDC Gull Wing 2000Cycles 2.54mm SMD T/R
Online Components:
Switch DIP ON OFF SPST 4 Raised Slide 0.1A 20VDC Gull Wing 2000Cycles 2.54mm SMD T/R
Electro Sonic:
Switch DIP ON OFF SPST 4 Raised Slide 0.1A 20VDC Gull Wing 2000Cycles 2.54mm SMD T/R
Win Source:
SWITCH SLIDE DIP SPST 100MA 20V / Dip Switch SPST 4 Position Surface Mount Slide Standard Actuator 100mA 20VDC
额定电压DC 20 V
针脚数 4
额定电流Max 0.1A @20VDC
工作温度Max 85 ℃
工作温度Min -55 ℃
额定电压 20 VDC
额定电压DC Max 20 V
接触电阻Max 25 mΩ
安装方式 Surface Mount
封装 DIP
长度 11.63 mm
宽度 9.91 mm
高度 4.3 mm
封装 DIP
触点材质 Beryllium Copper
工作温度 -55℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
219-4MSTR CTS 西迪斯 | 当前型号 | 当前型号 |
219-4LPSTR 西迪斯 | 完全替代 | 219-4MSTR和219-4LPSTR的区别 |
219-4LPSTRF 西迪斯 | 完全替代 | 219-4MSTR和219-4LPSTRF的区别 |
219-4MSTF 西迪斯 | 完全替代 | 219-4MSTR和219-4MSTF的区别 |
