24LC512-I/MF

MICROCHIP  24LC512-I/MF  EEPROM, AEC-Q100, 512 Kbit, 64K x 8位, 400 kHz, I2C, DFN, 8 引脚

The is a 512kB I²C serial Electrically Erasable Programmable Read-Only Memory EEPROM capable of operation across a broad voltage range 1.7 to 5.5V. It has been developed for advanced, low-power applications such as personal communications and data acquisition. This device also has a page write capability of up to 128 bytes of data. This device is capable of both random and sequential reads up to the 512K boundary. Functional address lines allow up to eight devices on the same bus, for up to 4Mb address space.

.

Low-power CMOS technology

.

2-wire serial interface I²C™ compatible

.

Cascadable up to eight devices

.

Schmitt trigger inputs for noise suppression

.

Output slope control to eliminate ground bounce

.

100 and 400kHz Clock compatibility

.

Page write time 5ms maximum

.

Self-timed erase/write cycle

.

128byte Page write buffer

.

Hardware write-protect

.

ESD protection >4000V

.

More than 1million erase/write cycles

.

Data retention >200 years
