25LC080T-I/SN

25LC080 系列 8 Kb 1 K x 8 5.5 V 表面贴装 SPI 总线 串行 EEPROM - SOIC-8

Description:

The Technology Inc. 25AA080/25LC080/25C080 25XX080

.

are 8 Kbit Serial Electrically Erasable PROMs. The memory is accessed via a simple Serial Peripheral Interface SPI compatible serial bus. The bus signals required are a clock input SCK plus separate data in SI and data out SO lines. Access to the device is controlled through a Chip Select CS input.

Features:

• Low-power CMOS technology:

  - Write current: 3 mA maximum

  - Read current: 500 A typical

  - Standby current: 500 nA typical

• 1024 x 8-bit organization

• 16 byte page

• Write cycle time: 5 ms max.

• Self-timed erase and write cycles

• Block write protection:

  - Protect none, 1/4, 1/2 or all of array

• Built-in write protection:

  - Power-on/off data protection circuitry

  - Write enable latch

  - Write-protect pin

• Sequential read

• High reliability:

  - Endurance: 1 M cycles

  - Data retention: > 200 years

  - ESD protection: > 4000V

• 8-pin PDIP and SOIC 150 mil

• Temperature ranges supported:

  - Industrial I: -40C to +85C

  - Automotive E 25C080: -40°C to +125°C
