2900017概述

Ethernet Radio, Wireless 900MHz RJ45 10/100Mbps, I/O Bus connections

The RAD-ISM-900-EN-BD… incorporates the MOTR-9™ radio board, a 1 watt, frequency-hopping, spread spectrum FHSS transceiver. It operates in the license-free 902-928 MHz ISM band. The MOTR-9™ provides userconfigurable over-the-air data rates up to 500 kbps. Adjustable packet sizes maximize data speed and minimize latency. The radio provides selectable 128/192/256-bit AES encryption to prevent unwanted intrusion and keep data secure.


艾睿:
Wireless Module


Allied Electronics:
Ethernet Radio, Wireless 900MHz RJ45 10/100 Mbps, I/O Bus connections


Verical:
Wireless Transceiver


MASTER:
Wireless Transceiver


Online Components:
Wireless Module


Electro Sonic:
Wireless Transceiver


2900017中文资料参数规格
技术参数

频率 902MHz ~ 928MHz

输入电流 250 mA

工作温度Max 65 ℃

工作温度Min -40 ℃

电源电压 11VDC ~ 30VDC

封装参数

安装方式 DIN Rail

外形尺寸

高度 99 mm

物理参数

工作温度 -40℃ ~ 65℃

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

海关信息

ECCN代码 5A002A1

HTS代码 8517620050

数据手册

在线购买2900017
型号: 2900017
描述:Ethernet Radio, Wireless 900MHz RJ45 10/100Mbps, I/O Bus connections
