Electromechanical Relay 24VDC 2.67KΩ 6A SPST-NO 80mm 6.2mm 94mm DIN Rail PLC Relay
**PLC-RSC Series**
PLC Interface single- and double-pole relays, and opto-couplers, having the same profile. This allows the modules to be installled in any configuration with a common bridging system and using the same accessories. The V8 adapter connects 8 relays or opto-couplers to a 15 way D-SUB cable.
得捷:
RELAY GEN PURPOSE SPST 6A 24V
艾睿:
PLC-INTERFACE for input functions, consisting of PLC-BSC/SEN basic terminal block with screw connection and plug-in miniature relay with power contact, for mounting on DIN rail NS 35/7,5, 1 N/O contact, input voltage24 V DC
Allied Electronics:
SPST DIN Rail Interface Relay Module Screw, 6A 24V dc
Verical:
Relay Module - PLC-RSC- 24DC/ 1/SEN
MASTER:
PLC-INTERFACE for input functions - consisting of PLC-BSC.../SEN basic terminal block with screw connection and plug-in miniature relay with power contact - for mounting on DIN rail NS 35/7,5 - 1 N/O contact - input voltage 24 V DC
Online Components:
Electromechanical Relay 24VDC 2.67KOhm 6A SPST-NO80x6.2x94mm DIN Rail PLC Relay
Electro Sonic:
PLC-INTERFACE for input functions - consisting of PLC-BSC.../SEN basic terminal block with screw connection and plug-in miniature relay with power ...
额定电压DC 250 V
额定电压AC 250 V
触点类型 SPDT
触点额定电流 6 A
线圈电压 24 VDC
线圈电流 9 mA
线圈电阻 2.67 KΩ
额定电流Max 6 A
线圈电压DC 24 V
额定功率Max 1.5 KVA
工作温度Max 60 ℃
工作温度Min -25 ℃
额定电压DC Max 250 V
额定电压AC Max 250 V
引脚数 5
长度 80 mm
宽度 94 mm
高度 94 mm
触点材质 Silver Tin Oxide
工作温度 -25℃ ~ 60℃
产品生命周期 Active
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8536410050
