Electromechanical Relay 24VDC 160Ω 6A 5PST-NO/SPST-NC 45mm 114.5mm 99mm DIN Rail Safety Relay

**PSRmini and PSRclassic Safety Relays from Contact:**

Emergency stop, light grid or safety door –
.
*the PSRmini and PSRclassic safety relays from Phoenix Contact** can be used to implement all safety functions for applications with one function, one device. With our **PSRmodular modular safety relay system** you can assemble your safety system as required.

**Features:**

* Versatile use – the ideal solution for every function

* Reliable thanks to force-guided contacts

* Fast installation and startup with user-friendly connection technology and DIN rail connector

* Tested safety, thanks to TÜV certification

* Space saving thanks to the slim overall width

2981224中文资料参数规格
技术参数

额定电流 6 A

通道数 1, 2

触点额定电流 6 A

线圈电流 155 mA

线圈电阻 154.8 Ω

线圈电压DC 24 V

工作温度Max 55 ℃

工作温度Min -20 ℃

额定电压 250 VAC

电源电压 250VAC, 250VDC

封装参数

安装方式 DIN Rail

外形尺寸

长度 45 mm

物理参数

工作温度 -20℃ ~ 55℃

其他

产品生命周期 Active

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

数据手册

在线购买2981224
型号: 2981224
描述:Electromechanical Relay 24VDC 160Ω 6A 5PST-NO/SPST-NC 45mm 114.5mm 99mm DIN Rail Safety Relay
