2056-20-B3LF

BOURNS  2056-20-B3LF  气体放电管 GDT, Light Duty, 2056系列, 200 V, 3终端通孔, 5 kA, 700 V

Protect your equipment from transient overvoltage events with Bourns" gas discharge tube. Its DC sparkover voltage is 200 V with a tolerance of ±20%, and its impulse discharge current 8x20 us, 10 Hits is 1 A. This item should be stored between -40 °C and 115 °C. This GDT has a minimum operating temperature of -30 °C and a maximum of 85 °C. It has 3 terminals/electrodes. The 2056-20-B3LF GDT has a radial termination style. This part has a lead diameter of 0.8 mm and a pitch of 3.8 mm. This product is 11.5 mm long and 6 mm.
