210-2MS

Switch DIP ON OFF SPST 2 Raised Slide 0.1A 20VDC PC Pins 1000Cycles 2.54mm Thru-Hole Tube

DIP SPST 2 位置 通孔 滑动式（标准） 触动器 100mA 20VDC

得捷:
SWITCH SLIDE DIP SPST 100MA 20V

欧时:
THROUGH HOLE, GOLD FLASH DIP SWITCH, 2-P

贸泽:
DIP Switches / SIP Switches 2 switch sections SPST

艾睿:
This 210-2MS dual in-line package switch from CTS can be easily customized and designed to be used on a printed circuit board. It has a SPST configuration. This device has a maximum current rating of 0.1 A @ 20VDC. This DIP switch has a minimum operating temperature of -40 °C and a maximum of 85 °C. The 210-2MS DIP switch has a PC pin termination style. This product is 6.55 mm long, 4.83 mm tall and 8 mm deep. This product&s;s terminal pitch is 2.54 mm. The maximum DC voltage rating is 20 VDC.

Verical:
Switch DIP ON OFF SPST 2 Raised Slide 0.1A 20VDC PC Pins 1000Cycles 2.54mm Thru-Hole Tube

MASTER:
Switch DIP ON OFF SPST 2 Raised Slide 0.1A 20VDC PC Pins 1000Cycles 2.54mm Thru-Hole Tube

Online Components:
Switch DIP ON OFF SPST 2 Raised Slide 0.1A 20VDC PC Pins 1000Cycles 2.54mm Thru-Hole Tube

Electro Sonic:
Switch DIP ON OFF SPST 2 Raised Slide 0.1A 20VDC PC Pins 1000Cycles 2.54mm Thru-Hole Tube
