206-10ST

206 系列 多功能 单刀单掷 10 位置 通孔 DIP 开关

is manufactured by Electrocomponents and is categorized in the DIP Switches category. 206-10ST is described as SWITCH SLIDE DIP SPST 50MA 24V. Perfect Parts is a supplier of Switches and other Electromechanicals.

艾睿:
Use CTS&s;s 206-10ST dual in-line package switch to easily control different electric paths on a printed circuit board. It has a SPST configuration. This device has a maximum current rating of 0.05 A @ 24VDC. This DIP switch has a minimum operating temperature of -55 °C and a maximum of 85 °C. The 206-10ST DIP switch has a PC pin termination style. This product is 27.58 mm long, 8.49 mm tall and 9.78 mm deep. The maximum DC voltage rating is 24 VDC. This product&s;s terminal pitch is 2.54 mm.

安富利:
Switch DIP OFF ON SPST 10 Raised Slide 0.05A 24VDC PC Pins 2.54mm Thru-Hole Tube

Chip1Stop:
Switch DIP OFF ON SPST 10 Raised Slide 0.05A 24VDC PC Pins 2.54mm Thru-Hole Tube

Verical:
Switch DIP OFF ON SPST 10 Raised Slide 0.05A 24VDC PC Pins 10000Cycles 2.54mm Thru-Hole Tube
