284093-4

Conn Eurostyle Block 4POS 5mm Solder RA Thru-Hole 13.5A/Contact

4 接线板 - 线至板 垂直，带板 0.197"（5.00mm） 通孔

得捷:
TERM BLK 4POS TOP ENTRY 5MM PCB

贸泽:
Fixed Terminal Blocks 4P TOP ENTRY 5mm

艾睿:
Perfect for troubleshooting this eurostyle block 284093-4 PCB terminal block manufactured from TE Connectivity will help isolate sections of a circuit. Its pitch is 5 mm. It has a maximum voltage rating of 300 VAC. This is a 1-row connector. It has a right angle body orientation. 284093-4 is housed in polyamide 6/6. This device has a maximum current rating of 13.5 A/contact. It uses the solder termination method. This product is 8.2 mm tall. Its wire is 16-30 AWG. This quick disconnect terminal has an operating temperature of -40 to 110 °C.

Chip1Stop:
Conn Eurostyle Block 4 POS 5mm Solder RA Thru-Hole 13.5A/Contact

Verical:
Conn Eurostyle Block HDR 4 POS 5mm Solder RA Thru-Hole 13.5A/Contact Box

MASTER:
TERMINAL BLOCK, PCB MOUNT TOP ENTRY WIRE, STACKING W/INTERLOCK, 5.00mm PITCH

Powell:
Terminal Block Connectors

Online Components:
TERMI-BLOK PCB MOUNT 90, 5,0MM

Electro Sonic:
TERMI-BLOK PCB MOUNT 90, 5,0MM
