282858-4

Conn Terminal Block F 4POS 10mm Solder ST Thru-Hole 24A/Contact

4P. TERMI-BLOK PCB MOUNT 90

Product Highlights

Connector

Connector Type = Wire Receptacle

Housing Color = Green

Not Side Stackable

Without Screw Flange

得捷:
TERM BLK 4P SIDE ENTRY 10MM PCB

艾睿:
Joining multiple circuits is easy with this eurostyle block 282858-4 PCB terminal block from TE Connectivity. This F connector&s;s 4 contacts that are made out of brass and plated with tin. Its pitch is 10 mm. It has a female type gender. It has a maximum voltage rating of 600 VAC. It has a straight body orientation. This is a 1-row connector. 282858-4 is housed in polyamide 6/6. This device has a maximum current rating of 24 A/contact. Its wire is 12-30 AWG. This product is 35.5 mm long, 19 mm tall and 10 mm deep. This quick disconnect terminal has an operating temperature of -40 to 105 °C. It uses the solder termination method.

安富利:
Conn Terminal Block F 4 POS 10mm Solder ST Thru-Hole 24A/Contact

Verical:
Conn Eurostyle Block F 4 POS 10mm Solder ST Thru-Hole 24A/Contact Carton

MASTER:
TERMINAL BLOCK, PCB MOUNT, SIDE ENTRY WIRE, 10.0mm PITCH

Powell:
Terminal Block Connectors

Online Components:
4P. TERMI-BLOK PCB MOUNT 90

Electro Sonic:
4P. TERMI-BLOK PCB MOUNT 90
