284414-8

Conn Eurostyle Block 8POS 3.5mm Solder RA Thru-Hole 12A/Contact Box

8 接线板 - 线至板 垂直，带板 0.138"（3.50mm） 通孔

得捷:
TERM BLK 8P TOP ENTRY 3.5MM PCB

艾睿:
Need to ensure strong connections between circuits? This eurostyle block 284414-8 PCB terminal block from TE Connectivity will do just that! It has a right angle body orientation. This is a 1-row connector. Its pitch is 3.5 mm. It has a maximum voltage rating of 300 VAC. 284414-8 is housed in polyamide 6/6. This device has a maximum current rating of 12 A/contact. This quick disconnect terminal has an operating temperature of -40 to 105 °C. This product is 8.2 mm tall. It uses the solder termination method.

Verical:
Conn Eurostyle Block HDR 8 POS 3.5mm Solder RA Thru-Hole 12A/Contact Box

Powell:
Terminal Block Connectors

Online Components:
TERMI-BLOK 900 PCB 8 POS 3,5 m

Electro Sonic:
TERMI-BLOK 900 PCB 8 POS 3,5 m
