Inductor High Current Toroid 120uH/88.5uH 15% 1kHz 2.2A 150mOhm DCR RDL
Resist changes in electric current flow in your electrical design with this high current leaded inductor from Bourns. This part has a pitch of 18.79 mm. This leaded inductor has an operating temperature range of -55 °C to 105 °C. This product is 11.43 mm tall with a diameter of 21.84 mm. It has an inductance of 120u/88.5uRated H. Its test frequency is 1K Hz. It has a tolerance of 15%. This device utilizes toroid technology. This leaded inductor has a maximum DC current of 2.2 A with a maximum resistance of 150m Ohm.
额定电流 2.2 A
容差 ±15 %
电感 120 µH
屏蔽 No
测试频率 1 kHz
电阻DC） ≤150 mΩ
工作温度Max 105 ℃
工作温度Min -55 ℃
电阻DC Max 150 mΩ
安装方式 Through Hole
引脚数 2
封装 Radial
宽度 0.45 in
高度 11.43 mm
直径 21.8 mm
封装 Radial
工作温度 -55℃ ~ 105℃
产品生命周期 Active
包装方式 Tray
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8504508000
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
2113-H-RC Bourns J.W. Miller 伯恩斯 | 当前型号 | 当前型号 |
2113-H 伯恩斯 | 完全替代 | 2113-H-RC和2113-H的区别 |
