HAMMOND 229C30 Isolation Transformer, Low Voltage, 24VA, 1 x 115V, 1 x 230V, 30V, 2 x 15V, 800mA
**Features:**
* CSA Certified File #LR3902
* UL Recognized File #E50394
* Universal Dual Primary 115/230 V, 50/60 Hz
* Low Primary to Secondary Coupling
* Balanced Windings
* No Electrostatic Shield Required
* Low EMF Radiation Due to Semi-Toroidal Design
* Dual — Split Bobbin Design
* High Insulation — Hi-Pot of 1,750 VRMS
* Class B Insulation — 130°C
* Low Profile Mounting
得捷:
PWR XFMR SEMI-TORO 24VA TH
Allied Electronics:
Transformer, low voltage pc mt, VA:24, Pri:115/230V, Sec:30V/.8A or 15V/1.6A
Verical:
Power Transformer 1750Vrms 24VA 8 Terminal PC Pin Thru-Hole
Newark:
# HAMMOND 229C30 Isolation Transformer, Low Voltage, 24 VA, 1 x 115V, 1 x 230V, 30V, 2 x 15V, 800 mA
MASTER:
transformer - power, low volt, pc mount
Online Components:
transformer - power, low volt, pc mount
