Power Transformer 117/234VAC Primary 24/48VAC Secondary 4/8A Output 192VA 50/60Hz
**Features:**
* Dual Primary 117/234 VAC, 50/60 Hz
* All Units Have Dual Secondaries, They Can Be Connected as a Center Tapped Winding or Used Individually
* Open Style, Chassis Mount with Minimum 6" Long Leads
* Dual Bobbin Design — No Electrostatic Shield Required
* Class B Insulation 130°C
* Hipot Test of 2,000 VRMS
* UL Listed — E50394, and CSA Certified — LR3902
* Meets NAFTA Requirements
得捷:
PWR XFMR LAMINATED 192VA CHAS MT
艾睿:
Power Transformer 2000Vrms 192VA 8Term. Wire Lead Flange Mount
Allied Electronics:
Transformer; Power; Config Bobbin; 1; Freq 50/60Hz; Pri 117/234VAC; Sec 24/48VAC; 8lbs.
Newark:
# HAMMOND 266N48 Isolation Transformer, 192 VA, 1 x 234V, 2 x 117V, 2 x 24V, 8 A, 266 Series
MASTER:
transformer - filament and low voltage rectifier/open
Online Components:
transformer - filament and low voltage rectifier/open
