Trans GP BJT NPN/PNP 40V 0.6A 6Pin CSMD
- 双极 BJT - 阵列 NPN,PNP 40V 600mA 600mW 表面贴装型 6-CLCC
得捷:
TRANS NPN/PNP 40V 0.6A 6CLCC
贸泽:
Bipolar Transistors - BJT NPN/PNP Transistor 6 Pin
艾睿:
Design various electronic circuits with this versatile npn and PNP 2N4854U GP BJT from Optek Technology TT electronics. This bipolar junction transistor&s;s maximum emitter base voltage is 5 V. Its maximum power dissipation is 600 mW. This bipolar junction transistor has a minimum operating temperature of -65 °C and a maximum of 200 °C. It has a maximum collector emitter voltage of 40 V and a maximum emitter base voltage of 5 V.
Allied Electronics:
6 PIN, SMT NPN/PNP COMPLEMENTARY TRANSISTORS
Verical:
Trans GP BJT NPN/PNP 40V 0.6A 600mW 6-Pin CSMD Waffle
耗散功率 0.6 W
击穿电压集电极-发射极 40 V
最小电流放大倍数hFE 100 @150mA, 10V
最大电流放大倍数hFE 300
额定功率Max 600 mW
工作温度Max 200 ℃
工作温度Min -65 ℃
耗散功率Max 600 mW
安装方式 Surface Mount
引脚数 6
封装 CLCC-6
长度 6.35 mm
高度 2.03 mm
封装 CLCC-6
材质 Silicon
工作温度 -65℃ ~ 200℃ TJ
产品生命周期 Obsolete
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Contains Lead
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
2N4854U TT Electronics/Optek Technology | 当前型号 | 当前型号 |
JANTXV2N4854U 美高森美 | 类似代替 | 2N4854U和JANTXV2N4854U的区别 |
JANTX2N4854U TT Electronics/Optek Technology | 功能相似 | 2N4854U和JANTX2N4854U的区别 |
