2-1445056-2

Conn Power HDR 2POS 3mm Solder RA SMD 2 Terminal 1Port

Connector Header Surface Mount, Right Angle 2 position 0.118" 3.00mm

得捷:
CONN HEADER 2POS RT ANG SMD TIN

贸泽:
Pin & Socket Connectors MICRO MNL HDR ASSY SINGLE ROW

艾睿:
Harsh and stressful environments are no match for this robust 2-1445056-2 power connector from TE Connectivity. This HDR connector&s;s 2 contacts that are made out of brass and plated with tin over nickel. This connector has a single port. Its pitch is 3 mm. It has a header type gender. It has a maximum voltage rating of 250 VAC. It has a right angle body orientation. 2-1445056-2 is housed in nylon. This device has a maximum current rating of 5 A/contact. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This product is 10 mm long, 5.67 mm tall and 11.16 mm deep. Its 2 terminals use the solder termination method. This power connector has a minimum operating temperature of -40 °C and a maximum of 105 °C.

安富利:
Conn Power HDR 2 POS 3mm Solder RA SMD 2 Terminal 1 Port

Chip1Stop:
Conn Power HDR 2 POS 3mm Solder RA SMD 2 Terminal 1 Port

Verical:
Conn Power HDR 2 POS 3mm Solder RA SMD 2 Terminal 1 Port T/R

MASTER:
RT ANGLE SURFACE MOUNT HEADER ASSY, TIN CONTACTS W/THRU HOLE HOLDDOWNS,

Powell:
3mm Centerline, 250V, 5 A max.
