2-87227-5

集管和线壳 UNSHRD VERT DUAL 50

50 MODII HDR DRST UNSHRD .100

得捷:
CONN HEADER VERT 50POS 2.54MM

贸泽:
集管和线壳 UNSHRD VERT DUAL 50

艾睿:
Make strong and binding connections on your circuit boards by adopting this unshrouded 2-87227-5 connector from TE Connectivity. This HDR connector&s;s 50 contacts that are made out of copper alloy and plated with gold over nickel. It has a header type gender. This is a 2-row connector. It has a straight body orientation. Its pitch is 2.54 mm. This device has a maximum current rating of 3 A/contact. This product is 63.09 mm long, 10.37 mm tall and 5.08 mm deep. 2-87227-5 is housed in black thermoplastic. It uses the solder termination method. This connector has an operating temperature of -65 to 105 °C.

安富利:
Conn Unshrouded Header HDR 50 POS 2.54mm Solder ST Thru-Hole

Newark:
# AMP - TE CONNECTIVITY  2-87227-5  Board-To-Board Connector, 2.54 mm, 50 Contacts, Header, AMPMODU Mod II Series, Through Hole, 2 Rows

MASTER:
ASSEMBLY, MOD II, HEADER, DOUBLE ROW, .100 X .100 CL. VERTICAL, .025 SQUARE POSTS

Powell:
.100 inch AMPMODU Headers

Online Components:
50 MODII HDR DRST UNSHRD .100

Electro Sonic:
50 MODII HDR DRST UNSHRD .100
