2-2106489-2

TE CONNECTIVITY  2-2106489-2  线至板连接器, 22 AWG, SSL系列, 2 触点, 插座, 4 mm, 通孔安装, 1 排

2 位置 单条导线 天然 IDC 22 AWG 通孔，直角

得捷:
CONN WIRE IDC 2POS 22AWG PCB RA

e络盟:
线至板连接器, 22 AWG, 4 mm, 2 触点, 插座, SSL系列, 通孔安装, 1 排

艾睿:
Look no further than the idc connector 2-2106489-2 header connector from TE Connectivity, a great tool to use when board-to-board interconnects is required. It has a right angle body orientation. It has a maximum voltage rating of 250 VDC|250VAC. Its pitch is 4 mm. This is a 1-row connector. This device has a maximum current rating of 8 A/contact. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This connector has an operating temperature of -40 to 105 °C. This product is 9.7 mm long, 5.8 mm tall and 7.75 mm deep. 2-2106489-2 is housed in green liquid crystal polymer. It uses the solder termination method.

Allied Electronics:
SSL Series, Right Angle Through Hole IDC Conn Socket, 2 Way, 1 Row, 4mm Pitch

安富利:
Conn IDC Connector M 2 POS 4mm IDT RA Cable Mount Tape

Chip1Stop:
Conn IDC Connector 2 POS 4mm Solder RA Thru-Hole Tape

Verical:
Conn IDC Connector 2 POS 4mm Solder RA Thru-Hole T/R

Newark:
# AMP - TE CONNECTIVITY  2-2106489-2  CONNECTOR, THRU HOLE-IDC, 2 POS, 22AWG New

MASTER:
ASSEMBLY, IDC SSL CONNECTOR, THROUGH HOLE, CLOSED END

Powell:
Lighting Connectors 2 Position 22 AWG Thru Hole Closed End

Online Components:
Connector, Thru Hole-IDC, 2 pos, 22AWG

Electro Sonic:
Connector, Thru Hole-IDC, 2 pos, 22AWG
