2-5535512-2

Conn Socket Strip SKT 30POS 2.54mm Solder RA Thru-Hole Tube

30 MODII HORZ DR CE EESS .100

Product Highlights

Receptacle

Mod II

Number of Positions = 30

Number of Rows = Dual

Standard Profile

得捷:
CONN RCPT 30POS 0.1 GOLD PCB R/A

艾睿:
Easily mount this socket strip 2-5535512-2 header connector from TE Connectivity onto your PCB project to support a variety of physical configuration options. This SKT connector&s;s 30 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a right angle body orientation. It has a socket type gender. This is a 2-row connector. Its pitch is 2.54 mm. This device has a maximum current rating of 2 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. 2-5535512-2 is housed in black polychlorinated terphenyl. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C. This product is 38.1 mm long, 6.05 mm tall and 8.13 mm deep.

安富利:
Conn Socket Strip SKT 30 POS 2.54mm Solder RA Thru-Hole Gang of Tubes

Chip1Stop:
Conn Socket Strip SKT 30 POS 2.54mm Solder RA Thru-Hole Tube

Verical:
Conn Socket Strip F 30 POS 2.54mm Solder RA Side Entry Thru-Hole Tube

MASTER:
AMPMODU MOD II RECEPTACLE ASSEMBLY, HORIZONTAL, .100 CL, 2 ROW, CLOSED-ENTRY, SHORT POINT OF CONTACT, END-TO-END STACKABLE

Powell:
.100 inch AMPMODU Receptacles

Online Components:
30 MODII HORZ DR CE EESS .100

Electro Sonic:
30 MODII HORZ DR CE EESS .100
