216602-4

Conn Socket Strip SKT 4POS 2.54mm Solder RA Thru-Hole

4P HV190 FEDERLEIS

Product Highlights

Receptacle

HV-190

Number of Positions = 4

Number of Rows = Single

Standard Profile

得捷:
CONN RCPT 4POS 0.1 GOLD PCB R/A

贸泽:
Headers & Wire Housings 4 POS RECPT R/A HV-190

艾睿:
Mount this socket strip 216602-4 header connector from TE Connectivity on a jumper post on your PCB to support physical configuration options. This SKT connector&s;s 4 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a socket type gender. It has a right angle body orientation. Its pitch is 2.54 mm. This is a 1-row connector. This device has a maximum current rating of 3 A/contact. 216602-4 is housed in green polyester. This connector has an operating temperature of -65 to 125 °C. This product is 10.16 mm long, 3.2 mm tall and 7.62 mm deep. It uses the solder termination method.

安富利:
Conn Socket Strip SKT 4 POS 2.54mm Solder RA Thru-Hole

Chip1Stop:
Conn Socket Strip SKT 4 POS 2.54mm Solder RA Thru-Hole

Verical:
Conn Socket Strip SKT 4 POS 2.54mm Solder RA Thru-Hole Box

Newark:
# AMP - TE CONNECTIVITY  216602-4  4P HV190 FEDERLEIS New

MASTER:
HV 190 HOR. ASSY SINGLE ROW, GOLD VERSION, MAX. 65 POSITION

Powell:
.100 inch AMPMODU Receptacles

Online Components:
4P HV190 FEDERLEIS

Electro Sonic:
4P HV190 FEDERLEIS
