215309-6

AMP FROM TE CONNECTIVITY  215309-6  矩形电源连接器, 垂直, HV-100系列, 焊接, 插座, 6 触点, 2.54 mm

The HV-100 series standard vertical surface-mount Receptacle with socket type contacts. This AMPMODU HV-100 series receptacle has gold-plated phosphor bronze contacts, LCP liquid crystal polymer housing and tin over nickel solder tail contact plating.

.

Stackable

得捷:
CONN RCPT 12POS 0.1 GOLD PCB

贸泽:
集管和线壳 REC ASSY 2X6P VERT HV-100

e络盟:
矩形电源连接器, 垂直, 6 触点, HV-100系列, 电路板安装, 焊接, 2.54 mm, 插座

艾睿:
Reduce the possibility of accidentally shorting pins when using a printed circuit board with this socket strip 215309-6 header connector from TE Connectivity. This SKT connector&s;s 12 contacts that are made out of phosphor bronze and plated with gold over nickel. This is a 2-row connector. It has a socket type gender. Its pitch is 2.54 mm. It has a straight body orientation. This device has a maximum current rating of 3 A/contact. This connector has an operating temperature of -65 to 105 °C. It uses the solder termination method. 215309-6 is housed in green polyester. This product is 15.24 mm long, 8.5 mm tall and 5.06 mm deep.

安富利:
Conn Socket Strip SKT 12 POS 2.54mm Solder ST Thru-Hole

Verical:
Conn Socket Strip SKT 6 POS 2.54mm Solder ST Thru-Hole Carton

Newark:
# AMP - TE CONNECTIVITY  215309-6  Rectangular Power Connector, Vertical, HV-100 Series, Solder, Receptacle, 6, 2.54 mm

MASTER:
HV 100 VERTICAL CONNECTOR, DUAL ROW, 8.5mm HEIGHT, TOP ENTRY , GOLD, MAX. 2X36 POSITIONS

Powell:
.100 inch AMPMODU Receptacles

Online Components:
2X6P HV100 REC CON. TE, 8.5MM

Electro Sonic:
2X6P HV100 REC CON. TE, 8.5MM
