282858-5

Conn Terminal Block F 5POS 10mm Solder ST Thru-Hole 24A/Contact

5 接线板 - 线至板 水平，带板 0.394"（10.00mm） 通孔

得捷:
TERM BLK 5P SIDE ENTRY 10MM PCB

艾睿:
Say goodbye to wires becoming undone by using this eurostyle block 282858-5 PCB terminal block developed by TE Connectivity. This F connector&s;s 5 contacts that are made out of brass and plated with tin. It has a female type gender. This is a 1-row connector. Its pitch is 10 mm. It has a straight body orientation. It has a maximum voltage rating of 600 VAC. This device has a maximum current rating of 24 A/contact. 282858-5 is housed in polyamide 6/6. It uses the solder termination method. Its wire is 12-30 AWG. This quick disconnect terminal has an operating temperature of -40 to 105 °C. This product is 45.5 mm long, 19 mm tall and 10 mm deep.

安富利:
Conn Terminal Block F 5 POS 10mm Solder ST Thru-Hole 24A/Contact

Verical:
Conn Eurostyle Block F 5 POS 10mm Solder ST Thru-Hole 24A/Contact Carton

Newark:
# AMP - TE CONNECTIVITY  282858-5  5P. TERMI-BLOK PCB MOUNT 90 New

MASTER:
TERMINAL BLOCK, PCB MOUNT, SIDE ENTRY WIRE, 10.0mm PITCH

Powell:
Terminal Block Connectors

Online Components:
5P. TERMI-BLOK PCB MOUNT 90

Electro Sonic:
5P. TERMI-BLOK PCB MOUNT 90
