Conn FPC Connector SKT 25POS 0.5mm Solder RA SMD T/R
Use this fpc connector flexible flat cable from in tightly constrained electronics projects. It has a maximum voltage rating of 250 VAC. This is a 1-row connector. This socket type connector"s 25 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a right angle body orientation. Its pitch is 0.5 mm. This device has a maximum current rating of 0.5 A/contact. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This product is 17.93 mm long, 2.05 mm tall and 5.1 mm deep. It uses the solder termination method. 2-1734592-5 is housed in natural liquid crystal polymer. This flexible flat cable has an operating temperature of -20 to 85 °C.
触点数 25
极性 Female
触点电镀 Gold
绝缘电阻 50 MΩ
排数 1
方向 Right Angle
易燃性等级 UL 94 V-0
针脚数 25
接触电阻 35 mΩ
屏蔽 No
额定电流Max 0.5A/触头
工作温度Max 85 ℃
工作温度Min -20 ℃
额定电压Max 250 VAC
额定电压 250 V
接触电阻Max 35 mΩ
安装方式 Surface Mount
长度 17.93 mm
宽度 5.1 mm
高度 2.05 mm
外壳颜色 Natural
触点材质 Phosphor Bronze
工作温度 -40℃ ~ 85℃
外壳材质 Thermoplastic
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 Signal
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
2-1734592-5 TE Connectivity 泰科 | 当前型号 | 当前型号 |
ZF5S-25-01-T-WT-TR 申泰电子 | 功能相似 | 2-1734592-5和ZF5S-25-01-T-WT-TR的区别 |
