Conn FPC Connector SKT 22POS 1mm Solder RA SMD T/R
1MM FPC HORZ.BTTM CONT.ASS.22P
Product Highlights
1.00 mm Centerline
Number of Positions = 22
PCB Mount Angle = Right Angle
PCB Mount Style = Surface Mount
Contact Type = Bottom
得捷:
CONN FPC BOTTOM 22POS 1MM R/A
艾睿:
This fpc connector 2-84952-2 flexible circuit from TE Connectivity can operate as a flexible medium between two different planes or decks. Its pitch is 1 mm. This socket type connector&s;s 22 contacts that are made out of phosphor bronze and plated with tin over nickel. It has a right angle body orientation. It has a maximum voltage rating of 200 VAC. This is a 1-row connector. This device has a maximum current rating of 1 A/contact. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This flexible flat cable has an operating temperature of -40 to 85 °C. It uses the solder termination method. 2-84952-2 is housed in natural liquid crystal polymer. This product is 29.92 mm long, 2.56 mm tall and 6.54 mm deep.
安富利:
Conn FPC Connector SKT 22 POS 1mm Solder RA SMD T/R
Chip1Stop:
Conn FPC Connector SKT 22 POS 1mm Solder RA SMD T/R
Verical:
Conn FPC Connector SKT 22 POS 1mm Solder RA SMD T/R
Newark:
# AMP - TE CONNECTIVITY 2-84952-2 FFC / FPC Board Connector, 1 mm, 22 Contacts, Receptacle, FPC Series, Surface Mount, Bottom
MASTER:
1MM FPC BOTTOM CONTACT LEADFREE
Powell:
FPC Flexible Printed Circuit Connectors
Online Components:
1MM FPC HORZ.BTTM CONT.ASS.22P
Electro Sonic:
1MM FPC HORZ.BTTM CONT.ASS.22P
触点数 22
极性 Female
触点电镀 Tin
额定电流 1 A
排数 1
方向 Right Angle
针脚数 22
屏蔽 No
额定电流Max 1A/触头
工作温度Max 85 ℃
工作温度Min -40 ℃
额定电压Max 200 VAC
额定电压 200 V
安装方式 Surface Mount
长度 29.92 mm
宽度 6.54 mm
高度 2.56 mm
外壳颜色 Natural
触点材质 Phosphor Bronze
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 Signal
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
ECCN代码 EAR99
HTS代码 8536694040
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
2-84952-2 TE Connectivity 泰科 | 当前型号 | 当前型号 |
