23J450概述

450Ω ±5% 3W ±30ppm/℃ Φ5.60mm

**Features

**

* Rugged Vitreous Enamel Coating Withstands High Humidity and Temperature Cycling

* Durable Construction, Recommended for Industrial Applications Where Reliability Is Paramount

* All-Welded Construction

* Flame-Resistant Vitreous Enamel Coating

* 5% Tolerance


得捷:
RES 450 OHM 5% 3W AXIAL


贸泽:
Wirewound Resistors - Through Hole 3watt 450ohm 5%


Allied Electronics:
RES 450 OHM 3W 5% AXIAL


Chip1Stop:
Res Wirewound 450 Ohm 5% 3W 30ppm/ C Conformal AXL


Verical:
Res Wirewound 450 Ohm 5% 3W ±30ppm/C Vitreous Enamel AXL


MASTER:
Res Wirewound 450 Ohm 5% 3W ±30ppm/°C Vitreous Enamel AXL


Online Components:
Res Wirewound 450 Ohm 5% 3W ±30ppm/°C Vitreous Enamel AXL


Electro Sonic:
Res Wirewound 450 Ohm 5% 3W ±30ppm/°C Vitreous Enamel AXL


23J450中文资料参数规格
技术参数

额定电压DC 135 V

容差 ±5 %

额定功率 3 W

产品系列 20

电阻 450 Ω

阻值偏差 ±5 %

额定电压 135 V

封装参数

安装方式 Through Hole

外形尺寸

长度 12.7 mm

直径 5.59 mm

物理参数

工作温度 25℃ ~ 350℃

温度系数 ±30 ppm/℃

其他

产品生命周期 Active

包装方式 Bulk

最小包装 250

符合标准

RoHS标准 Non-Compliant

含铅标准 Contains Lead

海关信息

ECCN代码 EAR99

HTS代码 8533210080

数据手册

23J450引脚图与封装图
23J450引脚图
23J450封装图
23J450封装焊盘图
在线购买23J450
型号: 23J450
制造商: Ohmite
描述:450Ω ±5% 3W ±30ppm/℃ Φ5.60mm
