23J400概述

400Ω ±5% 3W ±30ppm/℃ Φ5.60mm

**Features

**

* Rugged Vitreous Enamel Coating Withstands High Humidity and Temperature Cycling

* Durable Construction, Recommended for Industrial Applications Where Reliability Is Paramount

* All-Welded Construction

* Flame-Resistant Vitreous Enamel Coating

* 5% Tolerance


得捷:
RES 400 OHM 3W 5% AXIAL


贸泽:
Wirewound Resistors - Through Hole 3watt 400ohm 5%


Allied Electronics:
RES 400 OHM 3W 5% AXIAL


MASTER:
Res Wirewound 400 Ohm 5% 3W ±30ppm/°C Vitreous Enamel AXL


Online Components:
Res Wirewound 400 Ohm 5% 3W ±30ppm/°C Vitreous Enamel AXL


Electro Sonic:
Res Wirewound 400 Ohm 5% 3W ±30ppm/°C Vitreous Enamel AXL


23J400中文资料参数规格
技术参数

额定电压DC 135 V

容差 ±5 %

额定功率 3 W

产品系列 20

电阻 400 Ω

阻值偏差 ±5 %

额定电压 135 V

封装参数

安装方式 Through Hole

外形尺寸

长度 12.7 mm

宽度 12.7 mm

直径 5.59 mm

脚长度 38.1 mm

物理参数

材质 Ceramic

工作温度 25℃ ~ 350℃

温度系数 ±30 ppm/℃

其他

产品生命周期 Active

包装方式 Bulk

最小包装 250

符合标准

RoHS标准 Non-Compliant

含铅标准 Contains Lead

海关信息

ECCN代码 EAR99

HTS代码 8533210080

数据手册

23J400引脚图与封装图
23J400引脚图
23J400封装图
23J400封装焊盘图
在线购买23J400
型号: 23J400
制造商: Ohmite
描述:400Ω ±5% 3W ±30ppm/℃ Φ5.60mm
替代型号23J400
型号/品牌 代替类型 替代型号对比

23J400

Ohmite

当前型号

当前型号

23J400E

Ohmite

完全替代

23J400和23J400E的区别
