20761103100概述
ETHERNET SWITCH HARTING ECON 308
The Ethernet eCon Switches can be used in industrial environments and supports Ethernet 10 Mbit/s and fast Ethernet 100 Mbit/s. Up to 8 Ethernet devices can be connected via the RJ-45 ports. The Ethernet Switch supports a simple and quick network diagnostics with integrated LEDs at every port.- .
- *Features**: Store and forward switching mode, auto-crossing, auto-polarity, and auto-negotiation.
* Small Housing Format
* Robust Metal Housing
* Adapted for Mounting onto Top Hat Mounting Rail 35 mm According to EN 60 715
* UL Approved
20761103100中文资料参数规格
封装参数
安装方式 DIN Rail
其他
Series -
Type Switch - Unmanaged
Part-Aliases 020 020-76-110-3100 110 3100 76
Operating-Temperature -10°C ~ 70°C
Mounting-Type DIN Rail
Ingress-Protection IP30
Configuration Fixed
Connector-Type RJ45, SC
Voltage-Input 9.6 ~ 36VDC
Number-of-Ports 10
Fiber-Type 100BASE-FX Multimode
Copper-Ports 8
Copper-Type 10/100
Fiber-Ports 2
SFP-XFP-Ports -
SFP-XFP-Type -
PoE-Ports -
符合标准
RoHS标准 RoHS Compliant
含铅标准 Lead Free
