2SK2391

N CHANNEL MOS TYPE HIGH SPEED, HIGH VOLTAGE SWITCHING, CHOPPER REGULATOR, DC-DC CONVERTER AND MOTOR DRIVE APPLICATIONS

Chopper Regulator, DC−DC Converter and Motor Drive Applications

 4-V gate drive

 Low drain−source ON-resistance : RDS ON = 66 mΩ typ.

 High forward transfer admittance : |Yfs| = 16 S typ.

 Low leakage current : IDSS = 100 μA max VDS = 100 V

 Enhancement mode : Vth = 0.8 to 2.0 V VDS = 10 V, ID = 1 mA
