AP7333-18SAG-7

AP7333-18SAG-7 编带

PMIC - 稳压器 - 线性 输出 300mA SOT-23-3

立创商城:
正 Vin=6V Vout=1.8V~1.8V 300mA 65dB@100Hz

得捷:
IC REG LINEAR 1.8V 300MA SOT23-3

艾睿:
Stable voltages are always needed for sensitive systems implement this LDO AP7333-18SAG-7 linear regulator from Diodes Zetex. Its typical dropout voltage at current is 0.3@300mA V. This device has a maximum power dissipation of 600 mW. It has an overall accuracy of ±2 %. This voltage regulation device&s;s single output can produce a current up to 0.3 A. With a small input voltage of 2 V and a max of 6 V, this will supply sufficient power to your circuit. With a fixed output that has a voltage of 1.8 V, this is power management at its best. By operating at a load regulation of 0.6% and line regulation of 0.2%/V you can provide a constant voltage at your output. Its maximum power dissipation is 600 mW. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This voltage regulation device has an operating temperature range of -40 °C to 85 °C. Its polarity is positive.

Allied Electronics:
Voltage Regulators; LDO; LDO SOT-23 1.8V/300MA

Chip1Stop:
LDO Regulator Pos 1.8V 0.3A 3-Pin SOT-23 T/R

Verical:
LDO Regulator Pos 1.8V 0.3A 3-Pin SOT-23 T/R

Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 1.8V 300mA SOT-23-3

DeviceMart:
IC REG LDO 1.8V .3A SOT23
