正 Vin=3.65V Vout=0.8V~3.12V 3A
Linear Voltage Regulator IC 1 Output 3A 8-SO-EP
得捷:
IC REG LINEAR POS ADJ 3A 8SO
立创商城:
正 Vin=3.65V Vout=0.8V~3.12V 3A
贸泽:
LDO Voltage Controllers 3A ULTRA LDO LINEAR REG
艾睿:
This LDO AP7176BSP-13 linear regulator developed by Diodes Zetex keeps the power stable! It has an overall accuracy of ±1.5 %. Its typical dropout voltage at current is 0.33@3A|0.31@3A|0.3@3A V. This device has a maximum power dissipation of 1700 mW. This voltage regulation device&s;s single output can produce a current up to 3 A. By only needing an input voltage of 1.2 V with a maximum of 5.5 V, this is the best way to control the power in your circuit. With an adjustable output that has a voltage of 0.8Min V, this is power management at its best. At a load regulation of 0.06%Typ and line regulation of 0.15%/V your circuit is capable of maintaining a constant voltage level at your output. Its maximum power dissipation is 1700 mW. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This voltage regulation device has an operating temperature range of -40 °C to 85 °C. The maximum dropout voltage is 0.38@3A|0.36@3A|0.35@3A V. Its polarity is positive.
安富利:
LDO Regulator Pos 0.8V 3A 8-Pin MSOP-EP T/R
Chip1Stop:
LDO Regulator Pos 0.8V 3A 8-Pin SOP EP T/R
输出接口数 1
输出电压 0.8V ~ 5.17V
输出电流 3 A
耗散功率 1700 mW
跌落电压 0.33V @3A,0.3V @3A,0.31V @3A
输入电压Max 5.5 V
输入电压Min 1.2 V
输出电流Max 3 A
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 1700 mW
精度 ±1.5 %
输入电压 1.2V ~ 3.65V
安装方式 Surface Mount
引脚数 8
封装 SOP-8
封装 SOP-8
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
AP7176BSP-13 Diodes 美台 | 当前型号 | 当前型号 |
AP7175SP-13 美台 | 功能相似 | AP7176BSP-13和AP7175SP-13的区别 |
