Top Plunger Switch, 0.5, 0.25, 15A, 125VAC, 250VAC, 480VAC/125VDC/250VDC
E6 Series Enclosed Switch, Top Plunger Actuator Type
* Side or flange mount
* Momentary or maintained contact
* Grounding screw
* High capacity
* Pre-leaded or connector termination
It is offered with or without actuator seal boots. Both have a combination insulator/seal cemented inside the bottom enclosure. Lead washers are used to seal the mounting holes on side mount switches.
贸泽:
Limit Switches Top Plunger Actuator 14 NPT conduit
艾睿:
Thanks to Honeywell and their medium duty BZE6-7RNT limit switch, your microprocessor-based circuit can process information based on the switch&s;s position relative to the device itself. It has a SPDT configuration. BZE6-7RNT is housed in zinc die cast. This device has a maximum current rating of 15 A @ 480VAC. This limit switch has an operating temperature range of -32 °C to 71 °C. The BZE6-7RNT limit switch has a conduit termination style. The maximum AC voltage rating is 480 VAC and the maximum DC voltage rating is 250 VDC. This product is 71.04 mm tall.
Allied Electronics:
Top Plunger Switch, 0.5, 0.25, 15 A, 125 VAC, 250 VAC, 480 VAC/125 VDC/250 VDC
Chip1Stop:
Switch Limit N.O./N.C. SPDT Top Plunger Conduit 15A 480VAC 250VDC 7.78N Linear Screw Mount
Verical:
Switch Limit N.O./N.C. SPDT Top Plunger Conduit 15A 480VAC 250VDC 7.78N Linear Screw Mount
MASTER:
Switch Limit N.O./N.C. SPDT Top Plunger Conduit 15A 480VAC 250VDC 7.78N Linear Screw Mount
Electro Sonic:
Switch Limit N.O./N.C. SPDT Top Plunger Conduit 15A 480VAC 250VDC 7.78N Linear Screw Mount
