Diode Zener Single 16V 2% 350mW 3Pin SOT-23 T/R
Zener Diode 16V 300mW ±2% Surface Mount SOT-23
得捷:
DIODE ZENER 16V 300MW SOT23
贸泽:
Zener Diodes 350mW SMT PREC ZENER DIODE 3-39V
艾睿:
If your circuit requires a diode to operate in the reverse breakdown region, then this BZX84B16-7-F zener diode from Diodes Zetex is exactly what you need. Its maximum power dissipation is 350 mW. Its maximum leakage current is 0.1 μA. Its test current is 5 mA. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This zener device has a nominal voltage of 16 V and a voltage tolerance of 2%. It is made in a single configuration. This zener diode has a minimum operating temperature of -65 °C and a maximum of 150 °C.
Allied Electronics:
Zener Diode 16V 2% BZX84B 350mW SOT-23
安富利:
Diode Zener Single 16V 2% 350mW 3-Pin SOT-23 T/R
Verical:
Zener Diode Single 16V 2% 40Ohm 350mW 3-Pin SOT-23 T/R
容差 ±2 %
额定功率 350 mW
正向电压 900mV @10mA
耗散功率 350 mW
测试电流 5 mA
稳压值 16 V
正向电压Max 900mV @10mA
额定功率Max 300 mW
工作温度Max 150 ℃
工作温度Min -65 ℃
耗散功率Max 350 mW
安装方式 Surface Mount
引脚数 3
封装 SOT-23-3
长度 2.9 mm
宽度 2.4 mm
高度 1 mm
封装 SOT-23-3
工作温度 -65℃ ~ 150℃
温度系数 12.2 mV/℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
BZX84B16-7-F Diodes 美台 | 当前型号 | 当前型号 |
BZX84C15LT1G 安森美 | 功能相似 | BZX84B16-7-F和BZX84C15LT1G的区别 |
BZX84C13LT1G 安森美 | 功能相似 | BZX84B16-7-F和BZX84C13LT1G的区别 |
BZX84C18LT1G 安森美 | 功能相似 | BZX84B16-7-F和BZX84C18LT1G的区别 |
