二极管 - 通用，功率，开关 0.715V at 1mA 4ns 1.5pF Diode Array
Diode Array 2 Pair Series Connection Standard 75V 215mA DC Surface Mount SOT-563, SOT-666
立创商城:
75V 215mA 4ns
得捷:
DIODE ARRAY GP 75V 215MA SOT563
贸泽:
二极管 - 通用，功率，开关 0.715V at 1mA 4ns 1.5pF Diode Array
艾睿:
If your circuit needs to adjust from an AC to DC voltage use a switching diode BAV99BRV-7 rectifier from Diodes Zetex. Its maximum power dissipation is 350 mW. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. Its peak non-repetitive surge current is 4 A, while its maximum continuous forward current is 0.215 A. This rectifier has an operating temperature range of -65 °C to 150 °C. It is made in a double dual series configuration.
安富利:
Diode Switching 75V 0.215A 6-Pin SOT-563 T/R
Chip1Stop:
Diode Switching 75V 0.215A 6-Pin SOT-563 T/R
Verical:
Rectifier Diode Small Signal Switching 75V 0.215A 4ns 6-Pin SOT-563 T/R
额定功率 350 mW
正向电压 1.25 V
耗散功率 350 mW
反向恢复时间 4 ns
正向电流 215 mA
正向电压Max 1.25V @150mA
正向电流Max 0.215 A
工作温度Max 150 ℃
工作温度Min -65 ℃
耗散功率Max 350 mW
安装方式 Surface Mount
引脚数 6
封装 SOT-563
高度 0.6 mm
封装 SOT-563
工作温度 -65℃ ~ 150℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
