BAW56DW-7-F 编带
Diode Array 2 Pair Common Anode Standard 75V 150mA Surface Mount 6-TSSOP, SC-88, SOT-363
立创商城:
75V 150mA 4ns
得捷:
DIODE ARRAY GP 75V 150MA SOT363
艾睿:
If your circuit needs to adjust from an AC to DC voltage use a switching diode BAW56DW-7-F rectifier from Diodes Zetex. Its maximum power dissipation is 200 mW. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This rectifier has a minimum operating temperature of -65 °C and a maximum of 150 °C. Its peak non-repetitive surge current is 2 A, while its maximum continuous forward current is 0.15 A. It is made in a double dual common anode configuration.
安富利:
Diode Switching 75V 0.15A 6-Pin SOT-363 T/R
Chip1Stop:
Diode Switching 75V 0.15A 6-Pin SOT-363 T/R
Verical:
Rectifier Diode Small Signal Switching 75V 0.15A 4ns 6-Pin SOT-363 T/R
Win Source:
DIODE ARRAY GP 75V 150MA SOT363
额定电压DC 75.0 V
额定电流 50.0 mA
电容 2.00 pF
额定功率 200 mW
正向电压 1.25 V
反向恢复时间 4 ns
正向电流 0.15 A
正向电压Max 1.25V @150mA
正向电流Max 0.15 A
工作温度Max 150 ℃
工作温度Min -65 ℃
耗散功率Max 200 mW
安装方式 Surface Mount
引脚数 6
封装 SC-70-6
长度 2.2 mm
宽度 1.35 mm
高度 1 mm
封装 SC-70-6
工作温度 -65℃ ~ 150℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
BAW56DW-7-F Diodes 美台 | 当前型号 | 当前型号 |
BAW56DW-7 美台 | 类似代替 | BAW56DW-7-F和BAW56DW-7的区别 |
BAW56W-7-F 美台 | 功能相似 | BAW56DW-7-F和BAW56W-7-F的区别 |
BAW56T-7-F 美台 | 功能相似 | BAW56DW-7-F和BAW56T-7-F的区别 |
