0805 3.3uF ±10% 50V X6S
±10% 50V 陶瓷器 X6S 0805（2012 公制）
得捷:
CAP CER 3.3UF 50V X6S 0805
艾睿:
Get more with less with TDK&s;s C2012X6S1H335K125AC multilayer ceramic capacitor which uses multiple layers of ceramic and metal to act as dielectric and electrodes. It can withstand a voltage of 50 VDC. This MLCC capacitor has a maximum operating temperature of 105 °C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This product is 2 mm long, 1.25 mm tall and 1.25 mm deep. Its capacitance value is 3.3uF. It has a tolerance of 10%.
Chip1Stop:
Cap Ceramic 3.3uF 50V X6S 10% SMD 2.0 x 1.2 mm 105 C Plastic T/R
额定电压DC 50.0 V
电容 3.3 µF
容差 ±10 %
电介质特性 X6S
工作温度Max 105 ℃
工作温度Min -55 ℃
额定电压 50 V
安装方式 Surface Mount
封装公制 2012
封装 0805
长度 2 mm
宽度 1.25 mm
高度 1.25 mm
封装公制 2012
封装 0805
厚度 1.25 mm
材质 X6S/-55℃~+105℃
介质材料 Ceramic Multilayer
工作温度 -55℃ ~ 105℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 3000
制造应用 通用, Commercial Grade
RoHS标准 RoHS Compliant
含铅标准 Lead Free
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
C2012X6S1H335K125AC TDK 东电化 | 当前型号 | 当前型号 |
C2012X6S1H335M125AC 东电化 | 类似代替 | C2012X6S1H335K125AC和C2012X6S1H335M125AC的区别 |
C2012X6S1V335M125AB 东电化 | 功能相似 | C2012X6S1H335K125AC和C2012X6S1V335M125AB的区别 |
C2012X6S1E335K125AC 东电化 | 功能相似 | C2012X6S1H335K125AC和C2012X6S1E335K125AC的区别 |
