高速CMOS逻辑三路3输入或门 High-Speed CMOS Logic Triple 3-Input OR Gate
OR Gate IC 3 Channel 14-TSSOP
得捷:
IC GATE OR 3CH 3-INP 14TSSOP
立创商城:
CD74HC4075PWT
德州仪器TI:
3-ch, 3-input, 2-V to 6-V OR gates
艾睿:
CD74HC4075PWT logic gates from Texas Instruments are designed specifically to be interconnected and create a variety of different logic-based circuits. This gate has a minimum operating temperature of -55 °C and a maximum of 125 °C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This device has a typical operating supply voltage of 2.5|3.3|5 V. Its minimum operating supply voltage of 2 V, while its maximum is 6 V.
安富利:
OR Gate 3-Element 3-IN CMOS 14-Pin TSSOP T/R
Chip1Stop:
OR Gate 3-Element 3-IN CMOS 14-Pin TSSOP T/R
Verical:
OR Gate 3-Element 3-IN CMOS 14-Pin TSSOP T/R
电源电压DC 2.00V ~ 6.00V
输出接口数 1
输出电流 5.20 mA
电路数 3
位数 3
传送延迟时间 150 ns
电压波节 6.00 V, 5.00 V, 2.00 V
逻辑门个数 3
输出电流驱动 -1.00 mA
输入数 3
工作温度Max 125 ℃
工作温度Min -55 ℃
电源电压 2V ~ 6V
电源电压Max 6 V
电源电压Min 2 V
安装方式 Surface Mount
引脚数 14
封装 TSSOP-14
封装 TSSOP-14
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
CD74HC4075PWT TI 德州仪器 | 当前型号 | 当前型号 |
CD74HC4075PW 德州仪器 | 完全替代 | CD74HC4075PWT和CD74HC4075PW的区别 |
CD74HC4075PWRE4 德州仪器 | 完全替代 | CD74HC4075PWT和CD74HC4075PWRE4的区别 |
CD74HC4075PWTE4 德州仪器 | 完全替代 | CD74HC4075PWT和CD74HC4075PWTE4的区别 |
