八路缓冲器/线路驱动器，三态 OCTAL BUFFER/LINE DRIVERS, 3-STATE
Amplify analog and digital signals by driving the input to the transmission line with this buffer and line driver from Texas Instruments. With a 3-state output, this is power management at its best. This line driver has an operating temperature range of -55 °C to 125 °C. This device comes in tube packaging. This inverting device has a typical operating supply voltage of 1.8|2.5|3.3|5 V. Its minimum operating supply voltage of 1.5 V, while its maximum is 5.5 V. It has 8 channels per chip.
电源电压DC 1.50V ~ 5.50V
输出接口数 8
电路数 1
通道数 8
针脚数 20
位数 8
传送延迟时间 6.50 ns
电压波节 5.00 V, 3.30 V
输出电流驱动 -1.00 mA
输入数 8
工作温度Max 125 ℃
工作温度Min -55 ℃
电源电压 1.5V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 1.5 V
安装方式 Surface Mount
引脚数 20
封装 SOIC-20
长度 12.8 mm
宽度 7.52 mm
高度 2.35 mm
封装 SOIC-20
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Each
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
CD74AC540M TI 德州仪器 | 当前型号 | 当前型号 |
CD74AC540M96 德州仪器 | 完全替代 | CD74AC540M和CD74AC540M96的区别 |
CD74AC540ME4 德州仪器 | 完全替代 | CD74AC540M和CD74AC540ME4的区别 |
CD74AC540MG4 德州仪器 | 完全替代 | CD74AC540M和CD74AC540MG4的区别 |
