CRCW12068R20JNEAIF概述
VISHAY CRCW12068R20JNEAIF SMD Chip Resistor, Thick Film, 8.2Ω, 200V, 1206 [3216 Metric], 0.25W1/4W, ± 5%
The Vishay D/CRCW-IF e3 series Lead Pb-free thick film, rectangular, pulse proof chip resistors. The D/CRCW-IF e3 series resistors have Pure tin plating which provides compatibility with lead Pb-free and lead containing soldering processes.
- .
- High pulse performance
- .
- Metal glaze on high quality ceramic
- .
- Protective overglaze
- .
- Excellent stability ΔR/R
- .
- Lead Pb-free solder contacts on Ni barrier layer
CRCW12068R20JNEAIF中文资料参数规格
技术参数
额定电压DC 200 V
额定功率 250 mW
电阻 8.2 Ω
阻值偏差 ±5 %
工作温度Max 155 ℃
工作温度Min -55 ℃
额定电压 200 V
封装参数
安装方式 Surface Mount
引脚数 2
封装公制 3216
封装 1206
外形尺寸
长度 3.2 mm
宽度 1.6 mm
高度 0.55 mm
封装公制 3216
封装 1206
物理参数
工作温度 -55℃ ~ 155℃
温度系数 ±200 ppm/K
其他
包装方式 Cut Tape CT
制造应用 Portable Devices, Consumer Electronics, Automotive, Power Management, Industrial
符合标准
RoHS标准 Exempt
含铅标准 Lead Free
REACH SVHC标准 No SVHC
