MLCC-多层陶瓷电容器
MLCC-多层陶瓷器
得捷:
CAP CER 1800PF 50V C0G/NP0 0603
立创商城:
1.8nF ±5% 50V
艾睿:
You can&s;t go wrong with this CL10C182JB8NNNC multilayer ceramic capacitor from Samsung Electro-Mechanics, it is the most commonly used type of capacitor for multiple applications! It can withstand a voltage of 50 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. Its capacitance value is 0.0018uF. This product is 1.6 mm long, 0.8 mm tall and 0.8 mm deep. It has a tolerance of 5%.
安富利:
Cap Ceramic 0.0018uF 50VDC C0G 5% SMD 0603 Paper T/R
Verical:
Cap Ceramic 0.0018uF 50V C0G 5% Pad SMD 0603 125C T/R
Win Source:
CAP CER 1800PF 50V C0G/NP0 0603 / 1800 pF ±5% 50V Ceramic Capacitor C0G, NP0 0603 1608 Metric
额定电压DC 50.0 V
电容 0.0018 µF
容差 ±5 %
电介质特性 C0G/NP0
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 50 V
安装方式 Surface Mount
封装公制 1608
封装 0603
长度 1.6 mm
宽度 0.8 mm
高度 0.8 mm
封装公制 1608
封装 0603
厚度 0.8 mm
材质 C0G/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 4000
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
CL10C182JB8NNNC Samsung 三星 | 当前型号 | 当前型号 |
GRM1885C1H182JA01D 村田 | 功能相似 | CL10C182JB8NNNC和GRM1885C1H182JA01D的区别 |
GCM1885C1H182JA16D 村田 | 功能相似 | CL10C182JB8NNNC和GCM1885C1H182JA16D的区别 |
GCM1885C1H182JA16J 村田 | 功能相似 | CL10C182JB8NNNC和GCM1885C1H182JA16J的区别 |
