Relay SSR 15mA 140V AC-IN 65A 660V AC-OUT 4Pin
固态 SPST-NO（1 Form A） 带集成散热器的 SSR
得捷:
SSR RELAY SPST-NO 65A 48-660V
贸泽:
Solid State Relays - Industrial Mount DIN SSR 660Vac/65A 90-140Vac In,ZC
艾睿:
Solid State Relay 15mA 140V AC-IN 65A 660V AC-OUT 4-Pin
Allied Electronics:
RELAY; DIN SSR 660VAC/65A, 90-140VAC IN
Verical:
Relay SSR 15mA 140V AC-IN 65A 660V AC-OUT 4-Pin
Newark:
# CRYDOM CMRA6065 Solid State Relay, SPST-NO, 65 A, DIN Rail, Cage Clamp, 48 Vrms, 660 Vrms
Electro Sonic:
SOLID STATE RELAY 48-660 V - DIN SSR 660Vac/65A, 90-140Vac In,ZC
工作电压 600 V
输出电流 65000 mA
触点类型 SPST-NO
负载电流 65 A
输入电流 15 mA
隔离电压 4000 v
输出电压Max 660 V
输入电流Min 15 mA
负载电流Min 250 mArms
工作温度Max 80 ℃
工作温度Min -40 ℃
工作电压Min 48 Vrms
工作电压Max 660 Vrms
输入电压 90VAC ~ 140VAC
安装方式 Screw, DIN Rail
引脚数 4
封装 SSR with Integrated Heat Sink
宽度 45 mm
封装 SSR with Integrated Heat Sink
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
