96 W 单组输出 48 V 短路保护 LED 电源
2A 31.2 ~ 48V 恒定电流 LED 驱动器 AC DC 转换器 拓扑 1 输出
得捷:
LED DRIVER CC AC/DC 31.2-48V 2A
贸泽:
LED Power Supplies 96W 48V 2A LED Power Supply
艾睿:
Supply the proper amount of power to an LED by using this CEN-100-48 LED power supply manufactured by Mean-Well USA, Inc. This part&s;s single output can handle a current up to 2000 mA. This part has a minimum operating temperature of -30 °C and a maximum of 70 °C. The CEN-100-48 part has a lead wire termination style.
Allied Electronics:
Power Supply; AC-DC; 48V; 2A; 90-295V In; Enclosed; Desktop; LED Driver; CEN-100 Series
Jameco:
Enclosed Switching LED Power Supply PFC 48 Volts 2 Amps 96 Watts
富昌:
96 W 单组输出 48 V 短路保护 LED 电源
Chip1Stop:
AC/DC LED Power Supply 96W Single 5-Pin
TME:
Pwr sup.unit: switched-mode; LED; 96W; 48VDC; 43÷53VDC; 2A; IP66
MASTER:
AC/DC LED Power Supply - Const Curr - 96W - Fixed: 48 Vdc @ 2,000mA - Dim: No
Electro Sonic:
AC/DC LED Power Supply - Const Curr - 96W - Fixed: 48 Vdc @ 2,000mA - Dim: No
CDI:
LED Driver CC, CV 95W 1300-2000mA Linear 31.2-48Vdc 90-295Vac Non-Dimming IP66 Metal Enclosure
频率 63 Hz
额定功率 96 W
输出接口数 1
输出电压 48 V
输出电流 2 A
输入电流 1.4 A
输出功率 96 W
输出电流Max 2000 mA
输入电流Min 0.8 A
输出功率Max 62.4 W
工作温度Max 70 ℃
工作温度Min -30 ℃
电源电压 127.417VDC, 90.295VAC
输入电压 90V ~ 295V
安装方式 Panel
引脚数 5
封装 Metal Enclosure
长度 193 mm
宽度 62.5 mm
高度 40.5 mm
封装 Metal Enclosure
重量 600 g
工作温度 -30℃ ~ 70℃
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8504409520
