1.5KE20A-TP

ESD 抑制器/TVS 二极管 UNI-DIR 1500W 54.9A

Features

• Economical Series and Quick Response

• Available in Both Unidirectional and Bidirectional Construction

• 1500Watts Peak Power Dissipation

• Excellent Clamping Capability

• Lead Free Finish/RoHS CompliantNote 1 "P" Suffix designates RoHS Compliant. See ordering information

• UL Recognized File#E331408

• Epoxy meets UL 94 V-0 flammability rating

• Moisture Sensitivity Level 1

得捷:
TVS DIODE 17.1VWM 27.7VC DO201AE

立创商城:
Vrwm:17.1V 1.5kW

贸泽:
ESD 抑制器/TVS 二极管 UNI-DIR 1500W 54.9A

艾睿:
Surges can be a costly problem, avoid the pain and suffering by implementing this 1.5KE20A-TP TVS diode from Micro Commercial Components. Its peak pulse power dissipation is 1500 W. Its maximum leakage current is 5 μA. Its test current is 1 mA. This device&s;s maximum clamping voltage is 27.7 V and minimum breakdown voltage is 19 V. This TVS diode has an operating temperature range of -55 °C to 175 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery.
