147279-2

Conn Unshrouded Header HDR 10POS 2.54mm Solder ST SMD T/R

10 MODII HDR DR SFMT B/A T&R;

Product Highlights

Header

Header Type = Breakaway

Number of Rows = Dual

Number of Positions = 10

Mating Post Length = 5.84 mm

得捷:
CONN HEADER SMD 10POS 2.54MM

艾睿:
Use this unshrouded 147279-2 connector from TE Connectivity when board-to-board interconnects is required. This HDR connector&s;s 10 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 2.54 mm. It has a header type gender. It has a straight body orientation. This is a 2-row connector. This device has a maximum current rating of 3 A/contact. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. It uses the solder termination method. 147279-2 is housed in black liquid crystal polymer. This connector has an operating temperature of -65 to 105 °C. This product is 12.29 mm long, 9.73 mm tall and 7.42 mm deep.

Verical:
Conn Unshrouded Header HDR 10 POS 2.54mm Solder ST Top Entry SMD T/R

MASTER:
SURF. MT. HDR. ASSY, MOD II, B/W, VERT, D/R, .100 x .100 C/L, .025 SQ POST, W/ PICK AND PLACE CAP

Powell:
.100 inch AMPMODU Headers

Online Components:
10 MODII HDR DR SFMT B/A T&R

Electro Sonic:
10 MODII HDR DR SFMT B/A T&R
